Model LG LRDM1240W 01 Combo – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Common parts from model LG LRDM1240W 01 Combo
![CAPACITOR,[HIGH VOLTAGE]](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
CAPACITOR,[HIGH VOLTAGE] LGE 0CZZW1H001P Contact Us For Availability
33112U
OUT CASE, LGE 3112W0U024R Contact Us For Availability
33390G
TRAY,GLASS LGE 3390W1G004E Contact Us For Availability
43500A
BOARD,LATCH LGE 3500W1A010A Contact Us For Availability
54974S
GUIDE,SUCTION LGE 4974W1S048B Contact Us For Availability
56170D
TRANSFORMER,HIGH VOLTAGE LGE 6170W1D023L Contact Us For Availability
56201A
FILTER ASSY,NOISE LGE 2B72130H Contact Us For Availability
56411A
POWER CORD ASSEMBLY LGE 6411W1A033L Contact Us For Availability
56549F
MOTOR(CIRC),FAN LGE 6549W1F005P Contact Us For Availability
63302A
LGE 3302W0A025B LGE 3302W0A025B Contact Us For Availability
63303A
BASE PLATE ASSEMBLY LGE 3303W0A013C Contact Us For Availability
268712
PWB(PCB) ASSEMBLY,SUB LGE 6871W5S001C Contact Us For Availability
368771
HARNESS LGE 6877W1A467B Contact Us For Availability
568771
HARNESS LGE 6877W1A290E Contact Us For Availability
647781
LEG ALL LGE 4778W3A002A Contact Us For Availability
MAY000
LGE 3890W3C344A LGE 3890W3C344A Contact Us For Availability
MEZ173
LGE 3850W1D138B LGE 3850W1D138B Contact Us For Availability
MFL552
LGE 3828W5A8016 LGE 3828W5A8016 Contact Us For Availability
× ![]()
